STRAUB PIPE JOINING & REPAIRING SYSTEMS

STRAUB GRIP

Pipe Joining Coupling

Straub Grip, 76.1MM, EPDM sealing gasket

Technical Information

Casing / Locking parts

W5, W2

Sealing

EPDM / NBR / FPM/FKM sealing gaskets

Sizes

21.3mm - 711.2mm

Temperatures

-20 °C to +180 ° C

Medium

Water, air, solids and chemical products, gas, oil, fuel and other hydrocarbs

Pipe Material

Metal to metal / plastic to plastic

STRAUB GRIP Pipe Joining Couplings


Axially restraint type

METAL-GRIP

GRIP-L

ECO-GRIP

COMBI/PLAST GRIP

PLAST-PRO

Diameter 30.0mm to 609.6mm 26.9mm to 609.6mm 26.9mm to 168.3mm 40.0mm to 355.0mm 63.0mm to 355.0mm
Working pressure up to 67 bar up to 46 bar 6 bar 16 bar up to 16 bar
Sealing Gaskets EPDM, NBR EPDM, NBR, FPM/FKM EPDM, NBR EPDM, NBR PIPE MATERIAL
Temperatures -30°C to +100°C -20°C to +180°C -10°C to +40°C -20°C to +100°C -5°C to +40°C
Fireproofing possible YES YES NO NO NO
Side outlet possible YES NO NO NO NO
